5MP Auto Focus camera module with 30FPS

Product category:

USB Camera Board

SKU:

217155

Price:

$21.60

Description

Module No.	BM5M1908AF V22
Module Size	38mm × 38mm × 6.2mm±0.2MM
Temperature (Operation)	-30°C to 70°C
Temperature (Stable Image)	0°C to 50°C
Assembly technique	SMT (ROSH)
Focus	AUTO
Object distance	30CM-infinity
Resolution	800LW/PH (Center)
PCB printing ink	black
interface	USB 2.0
Power suuply	USB bus power
supply voltage	DC 5V±5%
Maximum Power consumption	800 mW
Operating system request	Win XP/win 7 8 / vista /android 4.0/ mac /Linux with uvc
Sensor	HM5040 (1/4" )
Seneor Package	CSP,Bare Die
Maximum resolution	2592*1944
Sensitivity	7500e /（lux-sec）
Pixel Size	1.4µm x 1.4µm
Maximum Image Transfer Rate	MJPEG 640x480 30FPS / YUY2 640X480 25FPS MJPEG 800x600 30FPS / YUY2 800X600 5FPS MJPEG 1280x720 30FPS / YUY2 1280X720 5FPS MJPEG 1920x1080 30FPS / YUY2 1920X1080 3FPS MJPEG 2592x1944 30FPS / YUY2 2592x1944 3FPS
S/N Ratio	38 db
Max Dynamic Range	66 db
Shutter type	Electronic rolling shutter
AGC/AEC/Whiter balance	Auto
Output Formats	YUY2/MJPEG
Microphone	Support
Lens Construction	4P
F/No	2.4
EFL	3.5 mm
FOV	65.8°
TV Distortion	<1.0%
Relative Illumination (Sensor)	70%
IR Filter	650±10nm
Module Package	Anti-electrostatic tray
Certifications	FCC/CE/ROSH
