Mini cmos camera module 2MP 1080P cmos image sensor IP PCB board camera

Product category:

Camera Board

SKU:

200985

Price:

$7.50

Description

Model No.	IF2653-32V1
Module	FH8626+1/2.9" GC2053
LUX	COLOR 0.05Lux@F1.2; B/W 0.005Lux@F1.2;
S/N	≥50db(AGC OFF)
WDR	DWDR；＞80db
Audio/Intercom Input	1CH MIC Input/linear input
Audio Output	1CH output
IO port	1CH RESET
SD card	NO
WIFI	NO
Coding Format	H.264
Mainstream	1920*1680，5-20FPS/S
Mainstream		1280*720，5-20 FPS/S
Substream	640*360 ,5-20 FPS/S
Video Coding Compression	128Kbps-8192bps continuous adjustable
Subtitle Overlay	Support channel name、Date、1 group of characters superposition adjustable
Data Record	Video,picture
Storage Method	Cycling Recording, Alarm Recording
Alarm Transfer	IO output, browser, management software
Protocol	All Net Connect / ONVIF 2.6
Browser	Support IE6.0 and above browser Client Browser
Temperature	-20℃ - +60℃
Humidity	0% - 90%
Power	DC12V /POE
power	1.5W
size	32* 32*10mm (without lens)
