Human Detection POE 4MP Full HD Starlight IP Camera PCB Board Module

Product category:

Camera Board

SKU:

201066

Price:

$9.70

Description

Features:

1/2.9" 4MP Super LOW Lux Black Light CMOS SENSOR WITH Fullhan 2K DSP,

single layer with 60mm*38mm;

support IR LED, warm led, Dual LED;

H.265+H.264 video coding,

Support body detection and human frame marking,

Main stream is 2560*1440, Sub stream is D1,

Enabled with ONVIF protocol

With bulit-in POE and led board driving circuit.

Gold-plated PCB board with better heat dissipation.

Specifications:

Model No.		H4P
Hardware
Module		Fullhan 2K DSP+1/2.9" 4MP CMOS
LUX		COLOR 0.01Lux F1.2; B/W 0.001Lux F1.2;
S/N		≥50db(AGC OFF)
WDR		DWDR; >80db
Port
Audio Input		1CH MIC Input
Audio Output		1CH MIC output, Speaker Optional
LED Board Function		LED Board Driving Circuit, Dual Light
IO port		1CH RESET, IR CUT, Alarm Input/Output
Others		Bulit-in POE, Support Standard POE Protocol
Video Coding
Coding Format		H.265/H.264
Resolution	Main Steam	2560*1440,1-30FPS/S
		23041296,19201080,1280*720,1-30 FPS/S
	Sub steam	704576,800448,640480,640360,352*288,1-30FPS/S
Video Coding Compression		128Kbps-8192bps continuous adjustable
Subtitle Overlay		Support Channel Name,Date & Time,Frame,Resolution,4 lines of character overlay
Data Transmission & Storage
Data Record		Video, picture
Storage Method		Cycling Recording, Alarm Recording
Alarm Transfer		IO output, browser, management software
Protocol		NETCOM / ONVIF 2.6
Mobile		Support IOS, Android
Browser		Support IE6.0 and above browser(insert Web Server),support 10 visitors in the same time(MAX)
Mobile Client		Support iPhone,iPad,Android
Temperature		-30℃ - +60℃
Humidity		0% - 90%
Power		DC12V-110mA /Built-in POE
power		1.3W
size		60* 38*10mm (without lens)
