CCTV 3MP IP Camera Module Hote Sale Camera PCB Board from Shenzhen China

Product category:

Camera Board

SKU:

200798

Price:

$4.50

Quantity	Price
1 - 999	$4.50
1000 - Unlimited	$4.00

Description

200798-CCTV-3MP-IP-Camera-Module-Hote-Sale-Camera-PCB-Board-from-Shenzhen-China-3.png

200798-CCTV-3MP-IP-Camera-Module-Hote-Sale-Camera-PCB-Board-from-Shenzhen-China-5.jpg

Model No.	H30
Module	Fullhan 1.5K DSP+1/4'' 3MP
LUX	Color 0.1Lux@F1.2;B/W 0.01Lux@F1.2
S/N	≥50db(AGC OFF)
WDR	DWDR; >80db
Audio Input	Audio MIC Input
Audio Output	1CH Outout Speaker Optional
LED TYPE	CDS IR LED & Warm LED & White LED(Support PWM)
IO Function	IR CUT & 1CH Reset & Alarm In & Alarm Out
Others	Extra Motorized Zoom Auto Focus Lens Optional
Coding Format	H.264
Main Steam	2304*1296
Main Steam
Sub Steam	704576,8001448,640480,640360,352*288
Video Coding Compression	128Kbps-8192bps Continuous Ajustable
Subtitle Overlay	Support Channel Name&Date&Time&Resolution&4 lines Characters adding
Data Record	Video & Picture
Storage Method	Cycling Recording & Alarm Recording
Alarm Transfer	IO output & Browser & Management Software
Protocol	Standard ONVIF Protocol
Mobile	Support IOS & Android
Browser	Support IE6.0 and above browser(insert Web Server)
Operation Temperature	-30℃ to +60℃
Humidity	0%-90%
Power	DC12V/90mA
Power	1.1W
Size	383810mm(without lens)
Weight	10g
