Model No.

N417R-V1

Spec.

2MP 4 IN 1 CMOS module

Model No.

1/2.8＂IMX307LQR+NVP2441H

Video Format

PAL/NTSC

Effective
Resolution

1920(H)x1080(V)

Illumination

0.0001Lux@(F1.2,AGC ON)，0LUX with IR

Shutter

AUTO

D/N Mode

External Control（Default）/Auto/Color/B&W

Synchronization

inter-sync

Frame rate

1080P@25fps / 1080P@30fps

Signal

AHD/TVI/CVI/CVBS (Optional)

Lens Mode

Manual/DC Lens

Exposure

Electronic Shutter/AGC/Frame /Brightness/DWDR/Fogging

Back-light
Mode

Close/Back-light Compensation/Strong Inhibition

W/B Mode

Auto/AWE/Indoor/Outdoor/Manual /AWB

D/N Mode

External Control（Default）/Auto/Color/B&W

DNR Type

2DNR/3DNR

Video Setting

Contrast/Sharpness/Saturation/DNR/Video Format/DWDR

Function

Equipment Name/Digital/Motion Detection /Privacy Block/Language/Bad Point Compensation/RS485

Adjustment

Sharpness/Display/Brightness/Compensation/NTSC/PAL

Exit

Save and Exit/Reset/Non-save

Language

Chinese1/Chinese2/German/French/
Italian/Spanish/Polish/Russian/Portuguese/
Dutch/Turkish/English

Working Temperature

-20℃ to 60℃
