4MP 1080P binocular synchronous camera module 3D reconstruction camera module

Product category:

USB Camera Board

SKU:

216547

Price:

$40.80

Quantity	Price
1 - 99	$40.80
100 - 499	$36.80
500 - Unlimited	$34.10

full product footer

Description

Product Parameter

Product Name	4MP Binocular Synchronized Camera Module
Module No	BM4M2214HD-2 V22-72
Module Size	80mm × 22mm × 24.5mm±0.5MM
Features	Dual 1080P HD VR, naked eye 3D, ranging, 3D reconstruction, vision applications and other embedded camera modules 1. Main performance dual 1080P High Definition 2. Can be customized to do with microphone (Charges apply)
Temperature (Operation)	-30°C to 70°C
Temperature (Stable Image)	0°C to 50°C
Assembly technique	SMT (ROHS)
Focus	Fixed
Object distance	30CM-infinity
Resolution	600LW/PH (Center)
PCB printing ink	Black
interface	USB2.0
Power suuply	USB bus power
supply voltage	DC 5V±5%
Maximum Power consumption	1100mW
Operating system request	Win XP/win 7 8 / vista /android 4.0/ mac /Linux with uvc
Sensor	OV4689(1/3")
Seneor Package	CSP,Bare Die
Maximum resolution	2688*1520
Sensitivity	1900mV /（lux-sec）
Pixel Size	2µm x 2µm
Maximum Image Transfer Rate	MJPEG 1280x480 30FPS / YUY2 1280x480 10FPS MJPEG 2160x1080 30FPS / YUY2 2160x1080 3FPS MJPEG 2560x720 30FPS / YUY2 2560x720 3FPS MJPEG 3040x1520 30FPS / YUY2 3040x1520 1FPS MJPEG 3840x1080 30FPS / YUY2 3840x1080 1FPS MJPEG 3840x1520 30FPS / YUY2 3840x1520 1FPS
S/N Ratio	38.3db
Max Dynamic Range	64.6db
Shutter type	Electronic rolling shutter
AGC/AEC/Whiter balance	Auto
Output Formats	YUY2/MJPEG
Microphone	NO
Lens Construction	2G2P
F/No	2.4
EFL	3.6 mm
FOV	72°
TV Distortion	<8%
Relative Illumination (Sensor)	70%
IR Filter	650±10nm
Module Package	Anti-electrostatic tray
Certifications	FCC/CE/ROHS
