2MP AHD Camera Module IMX323 Sensor CCTV Chipsets 1080P Starlight Camera PCB Board AHD/TVI/CVI/CVBS

full product footer

Description

Model	N4123-V1
Model No.	1/2.9＂IMX323+NVP2441H
Video Format	PAL/NTSC
Effective Resolution	1920(H)x1080(V)
Illumination	0.01Lux@(F1.2,AGC ON)，0LUX with IR
Shutter	AUTO
D/N Mode	Color（Default）/External Control/Auto/B&W
Synchronization	inter-sync
Frame Rate	1080P@25fps / 1080P@30fps
Video Output	AHD/TVI/CVI/CVBS (Optional)
Exposure	Electronic Shutter/AGC/Frame /Brightness/DWDR/Fogging
D/N Mode	External Control/Auto/Color/B&W
DNR Type	2DNR/3DNR
Video Setting	Contrast/Sharpness/Saturation/DNR/Video Format/DWDR
Function	Equipment Name/Digital/Motion Detection /Privacy Block/Language/Bad Point Compensation/RS485
Exit	Save and Exit/Reset/Non-save
Language	Chinese1/Chinese2/German/French/ Italian/Spanish/Polish/Russian/Portuguese/ Dutch/Turkish/English
Operation Temperature	-20℃ to 60℃
Working Humidity	Relative humidity less than 90 %
Power	DC12V(±20%) - 70mA
Size	3232/3838(mm)（±0.3mm）
